36-MSC1
Norden SC connector is a push pull type, gives an audible click when mates into its adaptor and can be tuned in 4 positions to provide the lowest insertion loss. It comprises of a body with ceramic ferrule/ spring/crimp barrel assembly plus a crimp over sleeve and rubber boot. These connectors are suitable for, 900μm and 2-3mm cables. The connector is precision made to demanding specifications. The combination of a ceramic ferrule with precision polymer housing provides consistent long-term mechanical and optical performance.
Norden SC connector is a push pull type, gives an audible click when mates into its adaptor and can be tuned in 4 positions to provide the lowest insertion loss. It comprises of a body with ceramic ferrule/ spring/crimp barrel assembly plus a crimp over sleeve and rubber boot. These connectors are suitable for, 900μm and 2-3mm cables. The connector is precision made to demanding specifications. The combination of a ceramic ferrule with precision polymer housing provides consistent long-term mechanical and optical performance.
| Part Number | Description |
|---|---|
| 36-MSC1 | SC/PC Multimode Connector |
| 36-LSC1 | SC/PC Laser Optimised Multimode(OM3/OM4) Connector |
| 36-SSC1 | SC/PC Singlemode Connector |
| 36-SSC3 | SC/APC Singlemode Connector |
